Digital Tire Pressure gauge HPM5 with Needle probe Tire Pyrometer, useful when you want to understand the tire footprint in order to optimize CAMBER and CASTER on car vehicles and the temperatures at different bike lean angles.

You can measure and save :

  • Tire Pressures
  • 12 Points of Tire Temperatures
  • Air Temperature
  • Track Temperature

Features:

  • Pressure Resolution : 0,001 BAR / 0.01 PSI
  • Pressure Range : 0 - 7 BAR (100 PSI)
  • Aluminum Tire chuck designed from Prisma Electronics for measurement without air loss from the wheel valve.
  • QUICK FUNCTIONS KEY

Wireless connection of the instruments through the Prisma Electronics APP to view and export all stored sessions.

ABS and COVER included.

Shipping : 24/48 Hours
Product Code : HPM5+PYR

In stock
Regular price €359,84 EUR
Sale price €359,84 EUR Regular price
TAX NOT INCLUDED
Shipping calculated at checkout.

DIGITAL TIRE PRESSURE GAUGE WITH NEEDLE PROBE PYROMETER FOR TEMPERATURE TREAD MEASUREMENT

FIRST OF ALL : ACCURACY

PRESSURE RESOLUTION: 0.001 BAR / 0.01 PSI

DESIGNED FOR MOTORSPORT

Aluminum tire chuck engineered by Prisma Electronics to ensure measurement without air loss from the wheel valve.

K-type thermocouple needle probe for tire temperature

Thanks to the high accuracy of this K-type thermocouple needle probe included with this Prisma Electronics digital tire pressure gauge, you can measure and save the tire compound temperature at three different points: EXTERNAL - MIDDLE - INTERNAL.

Useful when you want to understand the effect of the CAMBER and CASTER of cars and also temperatures at different lean angles of motorcycles. You can evaluate the dynamic set-up of the vehicle by evaluating the temperatures at all the different points of the tires.

CUSTOMIZABLE

The operating modes of the instruments can be easily configured using the quick-function buttons. In just a few moments, you can activate/deactivate various functions developed based on feedback from the teams we work with in major two-wheel and four-wheel championships.

QUICK-FUNCTIONS BUTTONS

You can change the operating mode of your instrument on the fly by simply pressing a button.

This feature allows you to set an offset value for the pressure, hiding the actual set value. This is useful, for example, in the pit lane or on the starting grid, when you want to hide the exact pressure value for strategic reasons. When the offset is active, the display shows the modified value, but you can always adjust the pressures accordingly. This function can be quickly activated or deactivated at any time using the quick-function buttons.

You can choose to store 8 pressure values (Cold and Hot) or just 4 pressure values. This is useful if you only want to measure Pit-Out or Pit-In pressures. Similarly, in Moto configuration, there will be only 4 or 2 pressure values.

Connect your Instrument with the App

With the new APP for the Hiprema5 gauges you can connect your instrument to the app for

ANALYZE - DOWNLOAD - SHARE - EXPORT

data of each session

SHARE THE PDF OF THE SESSION

YOU CAN SEND THE PDF FILE WITH THE DATA OF THE CURRENT SESSION DIRECTLY VIA WHATSAPP - EMAIL - CLOUD

INSTRUMENT CONFIGURATION

CONFIGURE AND UPDATE YOUR INSTRUMENT VIA THE APP OR BY THE INSTRUMENT'S MENU

Technical Features
DATA SAVED FOR EACH SESSION
  • 50 complete sessions saved in the internal memory of the instrument
  • Date and Time of each session
  • 12 Points of Tire Temperature
  • Track Temperature
  • Air Temperature
  • Cold and Hot pressure and relative difference
  • Vehicle number
PRESSURE SHOT® FUNCTION

A very easy of use way of quickly just checking the hot tyre pressure. By activating this function the pressure gauge save automatically the HOT tire pressures without pressing any buttons.
PRESSURE RESOLUTION

0.001 BAR - 0.1 PSI
CALIBRATION

Tire pressure gauge HPM5 does not require calibration. The internal microprocessor automatically performs the procedure in order to reach a reliable measure at 100%.
NEEDLE PROBE SPECS
  • Temperature Accuracy +/- 2°C
  • Temperature resolution 0.1°C
  • Temperature range 0 - 200°C
  • Response time +/- 3 sec
